Device Overview MC9S12G-Family
1.7.2.20.2
TXD[2:0] Signals
Those signals are associated with the transmit functionality of the serial communication interfaces SCI2-0.
1.7.2.21
1.7.2.21.1
CAN signals
RXCAN Signal
This signal is associated with the receive functionality of the scalable controller area network controller
(MSCAN).
1.7.2.21.2
TXCAN Signal
This signal is associated with the transmit functionality of the scalable controller area network controller
(MSCAN).
1.7.2.22
PWM[7:0] Signals
The signals PWM[7:0] are associated with the PWM module outputs.
1.7.2.23
1.7.2.23.1
Internal Clock outputs
ECLK
This signal is associated with the output of the divided bus clock (ECLK).
NOTE
This feature is only intended for debug purposes at room temperature.
It must not be used for clocking external devices in an application.
1.7.2.23.2
ECLKX2
This signal is associated with the output of twice the bus clock (ECLKX2).
NOTE
This feature is only intended for debug purposes at room temperature.
It must not be used for clocking external devices in an application.
1.7.2.23.3
API_EXTCLK
This signal is associated with the output of the API clock (API_EXTCLK).
1.7.2.24
IOC[7:0] Signals
The signals IOC[7:0] are associated with the input capture or output compare functionality of the timer
(TIM) module.
MC9S12G Family Reference Manual, Rev.1.23
Freescale Semiconductor
59
